WEREWOLF: Customizable 8′ Deluxe Skid Assembly – 3500 PSI, 5.5 GPM Cold Pressure Washer, 100 PSI, 7 GPM 12v Soft Wash System, RO/DI Window Cleaning System

Description

Skid:

• 8’L x 48″W Heavy Duty Deluxe Aluminum Skid with Ladder Rack & Side Shelves
  • Side Shelves are 19″ in depth
  • Fork Channels: 8″ Wide with 12″ between fork channels
• All Aluminum Construction for corrosion resistance
• Ladder Rack with Side Shelves is custom height adjustable and comes with rounded precision laser cut shelves with extreme duty bolt-on rounded support brackets & hardware.
• Built with the highest quality, USA produced aluminum and stainless hardened materials available to ensure many years of trouble free service & reliability.

Pressure Washer:

• 3500 PSI, 5.5 GPM Cold Water Pressure Washer
  • Honda V-Twin GX630 Gas Engine
    • Electric Start
  • 18 Amp High Output Charging System: to allow for the addition of a 12V hot box water heater
  • General Pump Brand, Belt-Driven Triplex Plunger Pump
  • External Unloader
  • Thermal Relief Valve
  • Aluminum Skid Frame
  • Genuine OEM Honda Muffler
  • 36″ Gun & Wand Assembly with Quick Connect Fittings
  • 200′ Grey High Pressure Hose with Quick Connects (this is what will be installed on the high pressure reel listed below
  • Quick Connect Color-Coded Spray Nozzles
  • Battery/ Battery Box
• Cool Bypass for Pressure Washer – protects the pressure washer pump from overheating when trigger is released
• Downstream Soap Injection for the Pressure Washer – Hi-Flow, 20% Adjustable
• Bleeder Valve / Pump Primer – bleeds air out of incoming water hose for pressure washer, allowing for easy start-up & preventing pump damage

Soft Wash System:

• 100 PSI, 7 GPM Remco Diaphragm Pump
• Accumulator Tank
• On/Off Toggle Switch
• Deep Cycle Battery & Battery Box
• NOCO Battery Charger
• Poly Gun/Wand Assembly with JROD
• Soft Wash Proportioner:
  • Solid Heavy Duty Manifold
  • Chemical Resistant Bleach Metering Valve
  • Water Metering Valve
  • Surfactant Metering Valve
  • Flush Valve for the Bleach Line

Tucker® RO/DI System: for spot-free window cleaning!

• (4) serviceable stainless steel housings
• (1) Chloramine / Carbon pre-filter rated for 80,000 gallons
• (2) Ultra low pressure reverse osmosis membranes for high production
• (1) DI Filter for ultra pure water
• Build in pressure gauge
• All metal fittings
• Powder coated steel frame with rubber feet
• Includes:
  • Waterproof On/Off Switch
  • Booster Pump
  • Tucker® 40 Carbon Fiber Pole

Install Package:

• Water Tank:
  • 200 Gallon Flat Bottom Tank – with heavy-duty hold-down bands
  • Tank Overflow Valve – 3/4″ water fill – stop water flow when tank is full and will continue to fill when water level drops
  • Tank Drain – 3/4″ drain hose with ball valve that drains to rear of truck
  • Heavy Duty Tank Filter
• Bleach Tank:
  • 55 Gallon Flat Bottom Tank – with fabricated aluminum hold-down bands
• Surfactant Tank:
  • 7 Gallon Flat Bottom Tank
• Hose Reels:
  • Inlet Reel – Titan 3/4″ x 100′ Max – Aluminum 12″ Barrel – 1″ Swivel
    • 100′ x 3/4″ Flexzilla inlet hose installed on reel
    • Locking Connectors: to secure hoses while in transit
  • Pressure Washer Reel – Titan 3/8″ x 300′ Max – Aluminum 12″ Barrel – 1/2″ Swivel – Stainless Steel Manifold
    • Comes with the 200′ x 3/8″ gray hose installed
    • Quick Connect Locking Connectors: to secure hoses while in transit
  • RO/DI Reel – Titan 3/8″ x 300′ Max – Aluminum 12″ Barrel – 1/2″ Swivel – Stainless Steel Manifold
    • Comes with the 150′ x 3/8″ yellow hose installed
    • Quick Connect Locking Connectors: to secure hoses while in transit
  • Soft Wash Reel – Titan 1/2″ x 200′ Max – Aluminum 12″ Barrel – 1/2″ Swivel – Stainless Steel Manifold
    • Comes with 200′ x 1/2″ Yellow Soft Wash Hose
    • Quick Connect Locking Connectors: to secure hoses while in transit
  • 12 Gallon Poly Fuel Tank
    • with fuel gauge
• (3) Heavy Duty Water Filters: to help keep debris out of your water tank, pressure washer pump, and soft wash pump
• Installation – installation of above components on deluxe aluminum skid, including labor, additional plumbing, hardware, & fittings
• Training – Operations, winterization, and safety & maintenance training provided at pick up.  Typically takes 30-90 minutes depending on the complexity of your build

Add -On Options: *All pictured in listing photos

• Downstream Manifold  – Pull up to three different soaps or chemicals using your downstream soap injector through the pressure washer. Each soap/chemical line plumbed with a ball valve to regulate which items you want to draw or have turned off.  This build can pull from the bleach tank, surfactant tank, and a “dip” line.  The “dip” line is an external hose that can be dropped into any bucket of chemical you may need to apply that you don’t have a tank for on-board (like bleach or surfactant).
• Surface Cleaner Mount – Easily and securely store your surface cleaner on top of your ladder rack!  Can be assembled to accommodate different sizes of surface cleaners.
• Upgrade All 4 Reels to 12v Electric Rewind Hose Reels – make winding up all of your hoses at the end of each job as easy as it gets!  Reduces clean-up time and fatigue with the bush of a button.

Check out our YouTube video below of the WEREWOLF build with all the add-ons!
