ASTEROID: Customizable 10′ Single Axle Open Trailer – 3500 PSI, 8 GPM Hot Washer – 2 Gun System

Description

Trailer:

• 5′ x 10′ Single Axle Open Trailer
• Single Axle with Electric Brakes
• 2990# GVWR
• Wood Decking

Pressure Washer:

• SS Series Hydro Tek
• 3500 PSI, 7.8 GPM
• Honda GX690 Engine with Electric Key Start
• V-Belt Drive General brand Triplex Plunger Pump
• Stainless Steel Frame & Panels
• Gas Driven, Diesel Fired
• Adjustable Temp to 200° F
• Schedule 80 Coil
• 12v Burner
• 8 Gallon Gas & Diesel Fuel Tanks
• Bleeder Valve / Pump Primer – bleeds air out of incoming water hose for pressure washer, allowing for easy start-up & preventing pump damage.
• (2) 48″ Wand Assembly  With Quick Connect Nozzles

Trailer Package:

• 200gal Flat Bottom Tank with HD Hold Down Bands
  • Tank Overflow Prevention Valve – 3/4″ Water Fill : shuts off water flow when tank is full & starts to fill again when tank water gets lower.
  • 1″ Tank Drain with Valve
• GP Hose Reel with Black Powder Coated Finish – 3/4″ x 100′ max Capacity (Inlet Reel)
  • 3/4″ x 100′ of Premium Flexzilla Pro Inlet Hose
• GP Hose Reel with Black Powder Coated Finish – 3/8″ x 300′ max Capacity (Pressure Washer – Gun 1)
  • 100′ of 4200 PSI Gray non-marking High Pressure Hose
• GP Hose Reel with Black Powder Coated Finish – 3/8″ x 300′ max Capacity (Pressure Washer – Gun 2)
  • 100′ of 4200 PSI Gray non-marking High Pressure Hose
• GP Stack Bracket Kit
• (2) Heavy Duty Water Tank T-Strainer Filters
• Downstream Soap Injection: Hi -Flow, 20% Adjustable Injector : Apply Detergents at Up to 20% (1:5) ratio. Easily Turn the Knob to Adjust to a 10% (1:10) Ratio.
• (2) 7 Gallon Soap Tanks
• (2) Stainless Steel Ball Valves: for switching between accessories
• 2-Gun Set Up:  Gives you the ability to use this washer as a single gun system at 3500 PSI, 8 GPM, or the ability to have two users on the system, each running at 3500 PSI, 4 GPM.
•  Installation – installation of above components into trailer, including labor, additional plumbing, hardware, & fittings
• Training – Operations, Maintenance & Safety Training provided at pick up.  Our technicians will provide hands on training so you are completely comfortable with your build before you leave our facility.   Training can be for one person or for your whole team.

Add-On Options:

• EZ Winterize System: Allows user to easily antifreeze the system to prevent freeze damage.  Includes 7 gallon reservoir tank.
• Ladder Rack
• Add 20″ Stainless Steel BE Whirl-A-Way Surface Cleaner
