GALAXY: 16′ Customizable Enclosed Tandem Axle Trailer – 3000 PSI, 7.8 GPM Hot Water Washer – 300 PSI, 11 GPM Gas Soft Wash – Tucker Ultimate Residential Window Cleaning Kit

Description

Trailer:

• 16′ x 7′ Enclosed Tandem Axle Utility Trailer with Upgraded 7′ Interior Height (standard is 6-6.5′)
• (2) Heavy Duty 3500lb Axles, 7000# GVWR
• Heavy Duty 2-5/16″ Hitch
• Side Entry Door
• Rear Double Doors

Hot Water Washer:

• 3000 PSI, 7.8 GPM – 9.3 GPM*
• Honda GX690 Engine with Electric (key) Start
• Belt drive triplex GP TSF-Series pump with ceramic plungers
• Honda GX690 Engine
  • Electric Start
  • Performance-proven OHV engine with low-oil protection
• Heavy-duty powder coated steel square tube skid frame
• Stainless-steel coil wrap, control panel and removable
  front panel
• Horizontal schedule 80 pipe coil
• 120V/15-amp auxiliary GFCI outlet
• 2900-watt generator for efficient power to the burner and controls
• No. 1 or No. 2 diesel or kerosene fired burner (Not approved for bio-fuel)
• 10 Gallon Engine & Burner Fuel Tanks
• Adjustable thermostat
• Hour meter
• Temperature rise 150°F/66°C above ambient, maximum outlet
  temperature is 200°F
• Bleeder Valve/Pump Primer– bleeds air out of incoming water hose for pressure washer, allowing for easy start-up & preventing pump damage
• Cool Bypass Pump Protection: protects the pressure washer pump from overheating when trigger is released

Soft Wash System:

• 300 PSI, 11 GPM
• Honda GX160 OR GX200 Gas Engine
• Comet P40 Diaphragm Pump
• 55 Gallon Vertical SH Tank
  • With custom made aluminum hold-down bands
• 18″ Hand-Crank 300′ Aluminum TITAN Reel with Stainless Steel Manifold
  • 1/2″ Stainless Steel Manifold
  • Max Capacity: 300′ x 1/2″ Soft Wash Hose
  • Comes with 300′ x 1/2″ Heavy Duty Chemical Resistant Hose
• Pressure Gauge on Soft Wash Reel
• Red Wash Down Gun
• Proportioner System for Soft Wash System:
  • Pull water, surfactant, and sodium hypochlorite without the need for batch mixing
  • Easily change solution ratios
  • Hi-Flow metering valves: no stress on pump and greater spray distance
  • Second soap valve optional
  • Flush Valve
  • Includes 7 gallon surfactant Tank
• Remote Rinse Systems for Gas Engine Soft Wash:
  • From a distance, you can flush out your soft wash system completely, or switch from pulling SH to water with the push of a button!

Residential Tucker Window Cleaning System

• The RIVAL Cart is a 4-stage Pure Water system that comes on a powder coated lightweight steel frame made for years of abuse. The new Tucker® combination sediment/carbon pre-filter makes this a 4-stage filtration system! Large flat free tires help you navigate all terrains.
• System consists of:
  • (1) Carbon pre-filter for removal of harsh chlorine, chloramine, and sediment.
  • (1) Rival Series reverse osmosis membrane.
  • (1) Refillable DI Filter for an ultra pure final polish of your pure water.
• Includes:
  • Tucker® Multi-Stage RO/DI Mobile Cart – RIVAL-V2
  • The Tucker® Hose Reel w/ 150′ of hose
  • The Tucker® ECO-30 Pole – BARE
  • The Tucker® Junior Pole – BARE
  • The Tucker® Standard Size Boar Hair Water Fed Brush with 4 Pencil Jets
  • The Tucker® Standard Size Hybrid Water Fed Brush with 2 Pencil Jets
  • The Tucker® Standard Size GLIDE Water Fed Brush with 4 Pencil Jets
  • The Tucker® Standard Size Over The Top Rinse Bar
  • The Tucker® Standard Size Alpha Scrubber
  • The Tucker® Mini Scrubber
  • A Male & Female Quick Connect For Pole Hose And Garden Hose
  • The Tucker® Reach Around Gooseneck w/ Quick Release For #1 Clamp
  • The Tucker® Swiveling Gooseneck w/ Quick Release For #1 Clamp
  • 100′ Of 5/16″ OD Tucker® Pole Hose
  • An Inline Ball Valve for 5/16″ OD Tucker® Pole Hose
  • An ACME Tip For #1 Clamp
  • A Wood Cone Tip for ACME Tip
• Tucker 12v Booster Pump

Trailer Package:

• 325 Gallon Water Tank – with heavy duty hold-down bands
• 20 Gallon Soap Tank
• Three Stacked Titan Hand Crank Hose Reels:
  •  18″ Hand-Crank 300′ Titan High Pressure Hose Reel (Pressure Washer)
    • 1/2″ Stainless Steel  Manifold for corrosion resistance
    • Max Capacity: 450′ x 3/8″ High Pressure Hose
    • Comes with 200′ High Pressure Hose – Gray
    • Stainless Steel Ball Valve – for easy switching between accessories
  • 18″ Hand-Crank 100′ Titan Inlet Hose Reel (Inlet)
    • 1″ Manifold for quicker tank fill
    • Max Capacity: 250′ x 3/4″ Inlet Hose
    • Comes with 100′ Flexzilla 3/4″ Inlet Hose
  • 18″ Hand-Crank 300′ Aluminum TITAN Reel (Soft Wash)
    • 1/2″ Stainless Steel Manifold
    • Max Capacity: 300′ x 1/2″ Soft Wash Hose
    • Comes with 300′ x 1/2″ Heavy Duty Chemical Resistant Hose
• (2) Stainless Steel Titan Stack Brackets
• Tank Overflow Valve – 3/4″ water fill – stop water flow when tank is full and will continue to fill when water level drops
• (3) Heavy Duty T-Strainers Water Filter: for easy cleaning
  • 1 Before the water tank, 1 before the pressure washer, 1 before the soft wash.
• 2″ Water Tank Drain with Valve to Outside Pass Side of Trailer: Easy hand wash or bucket fill access
• Wall Hooks & Hardware for Securing Wands
• Downstream Soap Injection: Includes stainless steel, hi-draw injectors
• Downstream Manifold for Pressure Washer – Pull up to three different soaps or chemicals using your downstream soap injector through the pressure washer. Each soap/chemical line plumbed with a ball valve to regulate which items you want to draw or have turned off.
• Chemical Resistant Protective Flooring: Protects wood floor of trailer from water & harsh chemicals.  Slip Resistant.  Gray Diamond plate pattern.  A 3R exclusive!
• Painted Interior Walls & Doors: Bright White Gloss
• Installation – installation of above components into the trailer, including labor, additional plumbing, hardware, & fittings
• Training – Operations, winterization, and safety & maintenance training provided at pick up.  Typically takes 30-90 minutes depending on the complexity of your build

Add-On Options:

• 30″ Mosmatic Surface Cleaner
• Aluminator Assembly
• Upgrade to 12v Electric Rewind Hose Reels
