KEELBACK: RAM 2500 High Top Van Install – Dual 8 GPM Pressure Washers with Optional 16 GPM cleaning

Description

**This equipment was installed in a 2025 RAM 2500 High Top Van.  Vehicles are to be supplied by the customer – 3R does not offer the option to purchase vans and/or box trucks through us.  If you’re looking for a custom install in a different style or model vehicle, please reach out to us via our contact form or through email and we’d be happy to get you an accurate quote for your available vehicle!

(2)  8 GPM Cold Water Pressure Washers

• 3500 PSI, 8 GPM
• 22hp Honda GX690 Gas Engine
• Electric Start
• Industrial Duty General Pump Triplex Plunger Pump
• High Amp Upgraded Charging System
• Block Mounted High-Flow Pressure Valve
• Thermal Relief Valve
• Ultra Rugged Corrosion Resistant Extruded Aluminum Frame
• Easy Access Two Piece Aluminum Belt Guard
• 4-Groove Bandit Belt for uniform tension & maximum power transfer
• Easy Engine & Pump Oil Drain System
• Quad Anti-Vibration Rubber Isolators
• 36″ Wand with 1/4″ QC Socket where spray nozzles attach
• Trigger Gun w/ Safety Lock-Off and 3/8″ QC Plug at inlet

Installation Package:

• Cool Bypass System for Pressure Washers:
  • protects the pressure washer pumps from overheating when trigger is released.
• Bleeder Valve / Pump Primer for each pressure washer
• (3) 100 Gallon Water Tanks
  • Heavy Duty Hold Down Bands
  • Tank Overflow Valve – 3/4″ water fill – stop water flow when tank is full and will continue to fill when water level drops
  • Tank Drain – 1″ Tank drain that drains to passenger side of van
• 55 Gallon Bleach Tank
• Titan 18″ Electric Rewind Aluminum High Pressure Hose Reel (Pressure Washer 1)
  • 1/2″ Stainless Steel Manifold
  • Premium Hose Guides
  • Holds max of 450′ of 3/8″ high pressure hose
  • 200′ x 3/8″ High Pressure Hose, Gray
  • Includes Locking Pin
  • Quick Connect Fitting Installed On Reel: to secure hose while in-transit
  • Stainless Steel Ball Valve: for easily switching between accessories
• Titan 18″ Electric Rewind Aluminum High Pressure Hose Reel (Pressure Washer 2 – or when both pressure washers are tied together)
  • 1/2″ Stainless Steel Manifold
  • Premium Hose Guides
  • Holds max of 300′ of 1/2″ high pressure hose
  • 200′ x 1/2″ High Pressure Hose, Black
  • Includes Locking Pin
  • Quick Connect Fitting Installed On Reel: to secure hose while in-transit
• Titan 18″ Electric Rewind Aluminum Inlet Hose Reel (Inlet Reel)
  • 1″ Manifold
  • Holds max of  200′ of 3/4″ hose
  • 150′ Flexzilla Inlet Hose
  • Includes Locking Pin
  • Fitting Installed On Reel: to secure hose while in-transit
• (2) Titan Stainless Steel Stack Brackets
• Downstream Soap Injection (for both washers): Includes stainless steel injector
• Downstream Manifold: Allows user to choose to draw soap into the pressure washer from 3 sources, BLEACH / SURFACTANT / DIP (soap line draw from 5 gal pail of your choice)
• Transfer Pump System:
  • REMCO 7 GPM Pump
  • Transfer Manifold – Allows you to easily transfer chemicals into your tanks without a mess or squeezing into inaccessible parts of your van!  Just drop your transfer pump hose into your concentrate outside of the vehicle, and select which tank (by turning the correct ball valve) you’d like to transfer the concentrate into.
• 7 Gallon Soap Tank
• Heavy Duty T-Strainer Water Filters:
  • 1 Filters Pre-Water Tank
  • 2 Filters Pre-Pressure Washer Pumps
• 22 Gallon Aluminum Fuel Tank
  • with gauge
• (3) 48″ x 40″ Aluminum Pallet Bases
  • with 4-way fork access
• Aluminum Table for Stacking Washers
• 24″ Stainless Steel BE Whirl-A-Way Surface Cleaner
• Installation – installation of above components into pictured van, including labor, additional plumbing, hardware, & fittings
• Training – Operations, winterization, and safety & maintenance training provided at pick up.  Typically takes 30-90 minutes depending on the complexity of your build

Add-On Options:

• EZ Winterizing System – quickly and easily winterize your whole system to protect against freezing.  Comes with 20 gallon tank for antifreeze.
• Spare Parts Kit: Convenient to keep on board your rigs if small repairs are needed!  We’ll stock this spare parts kit with some of the most common wearable parts & replacement parts needed regularly on a pressure washing / soft wash build.
