SIREN: Customizable 8′ Deluxe Skid Assembly – (2) 3500 PSI, 5.5 GPM Cold Pressure Washers & 100 PSI, 7 GPM 12v Soft Wash System

Description

Skid:

• 8’L x 48″W Heavy Duty Deluxe Aluminum Skid with Ladder Rack & Side Shelves
  • Side Shelves are 19″ in depth
  • Fork Channels: 8″ Wide with 12″ between fork channels
• All Aluminum Construction for corrosion resistance
• Ladder Rack with Side Shelves is custom height adjustable and comes with rounded precision laser cut shelves with extreme duty bolt-on rounded support brackets & hardware.
• Built with the highest quality, USA produced aluminum and stainless hardened materials available to ensure many years of trouble free service & reliability.

(2) Pressure Washers:

• 3500 PSI, 5.5 GPM Cold Water Pressure Washer
  • Honda V-Twin GX630 Gas Engine
    • Electric Start
  • 18 Amp High Output Charging System: to allow for the addition of a 12V hot box water heater
  • General Pump Brand, Belt-Driven Triplex Plunger Pump
  • External Unloader
  • Thermal Relief Valve
  • Aluminum Skid Frame
  • Genuine OEM Honda Muffler
  • 36″ Gun & Wand Assembly with Quick Connect Fittings
  • 200′ Grey High Pressure Hose with Quick Connects (this is what will be installed on the high pressure reel listed below
  • Quick Connect Color-Coded Spray Nozzles
• Cool Bypass for Pressure Washer – protects the pressure washer pump from overheating when trigger is released
• Downstream Soap Injection for the Pressure Washer – Hi-Flow, 20% Adjustable
• Bleeder Valve / Pump Primer – bleeds air out of incoming water hose for pressure washer, allowing for easy start-up & preventing pump damage

Soft Wash System:

• 12v Soft Wash System:
  • 100 PSI, 7 GPM Remco Diaphragm Pump
  • Accumulator Tank
  • On/Off Toggle Switch
  • Deep Cycle Battery & Battery Box
  • NOCO Battery Charger
  • Poly Gun/Wand Assembly with JROD
  • Soft Wash Proportioner:
    • Solid Heavy Duty Manifold
    • Chemical Resistant Bleach Metering Valve
    • Water Metering Valve
    • Surfactant Metering Valve
    • Flush Valve for the Bleach Line

Install Package:

• Water Tank:
  • 200 Gallon Flat Bottom Tank – with heavy-duty hold-down bands
  • Tank Overflow Valve – 3/4″ water fill – stop water flow when tank is full and will continue to fill when water level drops
  • Tank Drain – 3/4″ drain hose with ball valve that drains to rear of truck
  • Heavy Duty Tank Filter
• Bleach Tank:
  • 55 Gallon Flat Bottom Tank – with fabricated aluminum hold-down bands
• Surfactant Tank:
  • 7 Gallon Flat Bottom Tank
• Hose Reels:
  • Inlet Reel – Titan 3/4″ x 100′ Max – Aluminum 12″ Barrel – 1″ Swivel
    • 100′ x 3/4″ Flexzilla inlet hose installed on reel
    • Locking Connectors: to secure hoses while in transit
  • Two Pressure Washer Reels – Titan 3/8″ x 300′ Max – Aluminum 12″ Barrel – 1/2″ Swivel – Stainless Steel Manifold
    • Comes with the 200′ x 3/8″ gray hose installed on each reel
    • Quick Connect Locking Connectors: to secure hoses while in transit
  • Soft Wash Reel – Titan 1/2″ x 200′ Max – Aluminum 12″ Barrel – 1/2″ Swivel – Stainless Steel Manifold
    • Comes with 200′ x 1/2″ Yellow Soft Wash Hose
    • Quick Connect Locking Connectors: to secure hoses while in transit
  • (2) 12 Gallon Poly Fuel Tanks: one for each pressure washer
    • with fuel gauge
• (4) Heavy Duty Water Filters: to help keep debris out of your water tank and pressure washer / soft wash pumps
• Installation – installation of above components on deluxe aluminum skid, including labor, additional plumbing, hardware, & fittings
• Training – Operations, winterization, and safety & maintenance training provided at pick up.  Typically takes 30-90 minutes depending on the complexity of your build

Add -On Options:

• Downstream Manifold – Pull up to three different soaps or chemicals using your downstream soap injector through the pressure washer. Each soap/chemical line plumbed with a ball valve to regulate which items you want to draw or have turned off.  This build can pull from the bleach tank, surfactant tank, and a “dip” line.  The “dip” line is an external hose that can be dropped into any bucket of chemical you may need to apply that you don’t have a tank for on-board (like bleach or surfactant).
• Surface Cleaner Mount – Easily and securely store your surface cleaner on top of your ladder rack!  Can be assembled to accommodate different sizes of surface cleaners.

**Check Out the Original SIREN Build Below!**
