Florida LOCH NESS: Ready-Made 6′ Deluxe Aluminum Skid Assembly – 3500 PSI, 5.5 GPM Cold Water Washer – 12v Soft Wash System

Description

Pressure Washer:

• 3500 PSI, 5.5 GPM
• 20hp Honda GX630 Gas Engine
  • Electric Start
  • Hour Meter – for easy maintenance
• Heavy Duty General (GP) Triplex  Plunger Pump
• V-Belt Drive System
• External Unloader
• Thermal Relief Valve
• 36″ Gun & Wand Assembly
• Quick Connect Nozzles
• Aluminum Skid Mounted
• Cool Bypass for Pressure Washer – protects the pressure washer pump from overheating when trigger is released
• Downstream Soap Injection for the Pressure Washer – Hi-Flow, 20% Adjustable
• 11 Gallon Aluminum Fuel Tank – with gauge

12v Soft Wash System:

• 100 PSI, 7 GPM Remco Diaphragm Pump
• Accumulator Tank
• On/Off Toggle Switch
• Deep Cycle Battery & Battery Box
• NOCO Battery Charger
• 55 Gallon Bleach Tank -with custom fabricated, heavy-duty hold-down bands
• Gun/Wand Assembly with JROD
• Heavy Duty Tank Filter
• Soft Wash Proportioner:
  • Solid Heavy Duty Manifold
  • Chemical Resistant Bleach Metering Valve
  • Water Metering Valve
  • Surfactant Metering Valve
  • Includes: 7 Gal surfactant tank, hardware, plumbing, and installation

Skid:

• 6’L x 48″W Base Heavy Duty Deluxe Aluminum Skid with Adjustable Ladder Rack
• Water Tank:
  • 100 Gallon Flat Bottom Tank – with heavy-duty hold-down bands
  • Tank Overflow Valve – 3/4″ water fill – stop water flow when tank is full and will continue to fill when water level drops
  • Tank Drain – 3/4″ drain hose with ball valve that drains to rear of truck
  • Heavy Duty Tank Filter
• Hose Reels:
  • Inlet Reel – Titan 3/4″ x 100′ Max – Aluminum 12″ Barrel – 1/2″ Swivel
    • Comes with 100′ x 3/4″ Flexzilla inlet hose installed on reel
    • Locking Quick Connect Fittings
  • Pressure Washer Reel – Titan 3/8″ x 300′ Max – Aluminum 12″ Barrel – 1/2″ Swivel – Stainless Steel Manifold
    • Comes with the 200′ x 3/8″ gray hose installed on reel
    • Locking Quick Connect Fittings
  • Soft wash Reel – Titan 1/2″ x 200′ Max – Full-Frame Aluminum Hand Crank Hose Reel -with stainless steel manifold
    • with locking quick connects
    • 200′ x 1/2″ of Yellow Soft Wash Hose – Max 600 PSI
• Bleeder Valve / Pump Primer – bleeds air out of incoming water hose for pressure washer, allowing for easy start-up & preventing pump damage
• Group 24 Battery & Battery Box
• Installation – installation of above components on deluxe aluminum skid, including labor, additional plumbing, hardware, & fittings
• Training – Operations, winterization, and safety & maintenance training provided at pick up.  Typically takes 30-90 minutes depending on the complexity of your build

Add-On Options:

Please note that adding the below options in red can add an additional 1-2 business days to complete your skid.

• Surface Cleaner Rack – Aluminum surface cleaner rack installed. Includes hinged locking door for added security.  Fits up to 30″ surface cleaner.
• Add 19″ Surface Cleaner – Whisper Wash 19″ Yellow Hydro Flow Classic Surface Cleaner.  2 Stainless Steel Tips.
• Ball Valve Assembly – 5000 PSI Stainless Steel Ball Valve – allows you to switch between spray wand and surface cleaner without having to turn off your pressure washer.
• Add Aluminator Assembly
• Add Downstream Manifold – Choose between 3 different soap options or mix up to three soaps to draw through your pressure washer soap injector.   Ideal if you want to mix bleach with surfactant through your injector.  Includes installation.
• Upgrade Hand Crank Reels to All 12v Electric Rewind Hose Reels – Includes installation & circuit breaker

Approximate Overall Dimensions: 66″ D x 90″ W (including side shelves) x 51″ H***

**Installation of the assembly into your vehicle is not included.  Please contact us at 330-753-8394 for pricing on this service.

****Lead times may vary.  Please call our office for the most accurate production time  330-753-8394.

***Weights and overall dimensions are subject to change.  For questions, please contact the office at 330-753-8394.
