TAIPAN: Customizable 14′ Box Truck Install – (2) 8 GPM Cold Pressure Washers, 11 GPM Gas Soft Wash

TAIPAN: Customizable 14′ Box Truck Install – (2) 8 GPM Cold Pressure Washers, 11 GPM Gas Soft Wash

TAIPAN: Customizable 14′ Box Truck Install – (2) 8 GPM Cold Pressure Washers, 11 GPM Gas Soft Wash

$28,720.00

**Lead times may vary – standard production of a custom install takes two weeks.  Please call our office for the most accurate production time 330-753-8394.

Description

(2) Cold Water Pressure Washers:

  • 3500 PSI, 8 GPM
  • Honda GX690 Gas Engine with Electric Start
  • Belt Drive General Pump Industrial Series Triplex Pump
  • Powder Coated Skid Frame
  • Battery Cables
  • External Unloader & Thermal Relief Valve
  • Downstream Soap Injection – 20% adjustable draw
  • Bleeder Valve / Pump Primer – bleeds air out of incoming water hose for pressure washer, allowing for easy start-up & preventing pump damage

Gas Soft Wash System:

  • 300 PSI, 11 GPM
  • Honda GX160 Gas Engine
  • Engine Oil Drain Hose
  • Corrosion Resistant Aluminum Skid Frame
  • Anti-Vibration Rubber Isolators
  • Featuring the Comet P40 Pump or AR45 Pump
  • Proportioner System for Soft Wash:
    • Pull water, surfactant, and sodium hypochlorite without the need for batch mixing
    • Easily change solution ratios
    • Hi-Flow metering valves: no stress on pump and greater spray distance
    • Second soap valve optional
    • Flush Valve
    • Custom fabricated brackets for mounting
    • 7 Gallon Surfactant Tank
  • 55 Gallon S/H Tank
  • High Flow Rear Entry Red Wash Down Gun

Trailer Package:

  • 525 Gallon Water Tank
    • Tank Overflow Valve – 3/4″ water fill – stop water flow when tank is full and will continue to fill when water level drops
    • Tank Drain – 2″ Ball Valve that releases to the of the passenger side of the van
    • Heavy Duty Water Tank Filter – to help keep debris out of your equipment
    • Garden Hose Fitting for Easy Connection of Inlet Hose
    • Heavy Duty Hold-Down Bands
  • Cool Bypass System for Pressure Washers – protects the pressure washer pumps from overheating when triggers are released.
  • Titan Aluminum High Pressure Hose Reel (for pressure washer #1)
    • 1/2″ Stainless Steel Manifold
    • Holds max of 400′ of 3/8″ hose
    • 200′ High Pressure Hose, Gray, 1WB, 4200 PSI
    • Includes Locking Pin
    • Quick Connect Fitting Installed On Reel: to secure hose while in-transit
  • Titan Aluminum High Pressure Hose Reel (for pressure washer #2)
    • 1/2″ Stainless Steel Manifold
    • Holds max of 400′ of 3/8″ hose
    • 200′ High Pressure Hose, Gray, 1WB, 4200 PSI
    • Includes Locking Pin
    • Quick Connect Fitting Installed On Reel: to secure hose while in-transit
  • Titan Aluminum Inlet Hose Reel
    • Stainless Steel Manifold
    • Holds max of 150′ of 3/4″ hose
    • 100′ Flexzilla Inlet Hose
    • Includes Locking Pin
    • Quick Connect Fitting Installed On Reel: to secure hose while in-transit
  • Titan Aluminum Soft Wash Hose Reel (Gas SW):
    • Stainless Steel Manifold
    • Holds max of 200′ x 1/2″ hose
    • Includes 200′ x 1/2″, 600 PSI yellow soft wash hose
    • Includes Locking Pin
  • (3) Titan Stack Brackets & Additional Custom Fabricated Supports
  • Fuel Access Door – for easy access to fuel tanks inside of van, on the same side as the van fuel fill.
  • Downstream Soap Injection – 20% Adjustable, stainless steel injector.
  • Installation – installation of above components into pictured van, including labor, additional plumbing, hardware, & fittings
  • Training – Operations, winterization, and safety & maintenance training provided at pick up.  Typically takes 30-90 minutes depending on the complexity of your build



Add-On Option:

*This install fits into a 7.5′ x 14′ Chevy box truck.  For installs in vehicles that do not have the same dimensions as this style, please contact our Build Team at 330-753-8394 for a custom quote!  Pricing does not include the vehicle itself.  Vehicles are to be provided by the customer.
