Florida YETI: Ready Made 8′ Deluxe Aluminum Skid Assembly – 3500 PSI, 8 GPM Cold Water Washer – Gas Engine Soft Wash System

Description

• Pressure Washer:
  • 3500 PSI, 8 GPM
  • Cold Water
  • Honda GX690 Gas Engine
    • Electric Start
  • Aluminum Skid Frame
  • 11 Gallon Aluminum Fuel Tank with Gauge
  • Battery & Battery Box
  • 36″ Gun & Wand Assembly with Quick Connect Fittings
  • 200′ High Pressure Hose with Quick Connects (this is what will be installed on the high pressure reel listed below)
  • Quick Connect Color-Coded Spray Nozzles
• Cool Bypass for Pressure Washer – protects the pressure washer pump from overheating when trigger is released
• Downstream Soap Injection for the Pressure Washer – Hi-Flow, 20% Adjustable
• Gas Engine Soft Wash System:
  • Includes:
    • 290 PSI, 11 GPM Diaphragm Pump – AR45 or Comet P40 (Which pump is used depends on availability.  Pictured is the P40.)
      • Electric Start
    • Honda GX160 or 200 Engine
    • 18″ Titan Full-Frame Aluminum 12v Electric Rewind Hose Reel -with stainless steel manifold
    • 300′ x 1/2″ of Yellow Soft Wash Hose – Max 600 PSI
    • 55 Gallon Bleach Tank -with custom fabricated, heavy-duty hold-down bands
    • Red Wash Down Gun
    • Heavy Duty Tank Filter
    • Soft Wash Proportioner:
      • Solid Heavy Duty Manifold
      • Chemical Resistant Bleach Valve
      • Water Valve
      • Surfactant Valve
      • Includes: 7 Gal surfactant tank, hardware, plumbing, and installation
• Skid:
  • 8’L x 48″W Base Deluxe Aluminum Skid with Adjustable Ladder Rack, Driver & Passenger Side Shelves, and Third Tailgate Shelf.  Total width approximately 7′ 8″.
• Water Tank:
  • 200 Gallon Flat Bottom Tank – with heavy-duty hold-down bands
  • Tank Overflow Valve – 3/4″ water fill – stop water flow when tank is full and will continue to fill when water level drops
  • Tank Drain – 3/4″ drain hose with ball valve that drains to rear of truck
  • Heavy Duty Tank Filter
• Hose Reels:
  • Inlet Reel – 12v Electric Rewind Titan 3/4″ x 200′ Max – Aluminum 18″ Barrel – 1/2″ Swivel
    • Comes with 100′ x 3/4″ Flexzilla inlet hose installed on reel
  • Pressure Washer Reel – 12v Electric Rewind Titan 3/8″ x 300′ Max – Aluminum 18″ Barrel – 1/2″ Swivel – Stainless Steel Manifold
    • • Comes with the 200′ x 3/8″ gray hose installed on reel
• Battery & Battery Box:
  • • • • to provide power to electric starts on machines
• Bleeder Valve / Pump Primer – bleeds air out of incoming water hose for pressure washer, allowing for easy start-up & preventing pump damage
• Installation – installation of above components on deluxe aluminum skid, including labor, additional plumbing, hardware, & fittings
• Training – Operations, winterization, and safety & maintenance training provided at pick up.  Typically takes 30-90 minutes depending on the complexity of your build
• Dimensions: 94″L x 48″W x 49″H*
• Dry Weight: 1,075lbs*

Add On Options Available:

Please note that adding the below options in red can add an additional 1-2 business days to complete your skid.

• Surface Cleaner Rack – Aluminum surface cleaner rack installed. Includes hinged locking door for added security.  Fits up to 30″ surface cleaner.
• Add 24″ Surface Cleaner – Whisper Wash 24″ Ground Force XFORCE Stainless Steel Performance Surface Cleaner.  4 Tips.
• Ball Valve Assembly – 5000 PSI Stainless Steel Ball Valve – allows you to switch between spray wand and surface cleaner without having to turn off your pressure washer.
• Add Aluminator Assembly
• Add Downstream Manifold – Choose between 3 different soap options or mix up to three soaps to draw through your pressure washer soap injector.   Ideal if you want to mix bleach with surfactant through your injector.  Includes installation.
• Remote Rinse for Gas Engine Soft Wash – turns off your chemical draw and pulls from water tank.  Flushes bleach from your system and allows for a fresh water rinse.  Includes installation.

**Installation of the assembly into your vehicle is not included.  Please contact us at 330-753-8394 for pricing on this service.

****Lead times may vary.  Please call our office for the most accurate production time  330-753-8394.

***Weights and overall dimensions are subject to change.  For questions, please contact the office at 330-753-8394.
