COBRA: Customizable 14′ Ford F-350 Transit High Top Cargo Van Installation – Two 8 GPM Cold Pressure Washers, 7 GPM 12v Soft Wash

$30,201.00

Choose as few or as many of these add-on options to your trailer as you’d like! The pictures on this listing include ALL of the add-on products listed.

**Lead times may vary – standard production of a custom install takes two weeks.  Please call our office for the most accurate production time 330-753-8394.

Description

Two Cold Water Pressure Washers:

  • 3500 PSI, 8 GPM
  • Honda GX690 Gas Engine with Electric Start
  • Belt Drive General Pump Industrial Series Triplex Pump
  • Powder Coated Skid Frame
  • Battery Cables
  • External Unloader & Thermal Relief Valve
  • Downstream Soap Injection
  • Bleeder Valve/Pump Primer

12V Soft Wash System:

  • 100 PSI, 7 GPM Remco Diaphragm Pump
  • 200′ x 1/2″ of Yellow Soft Wash Hose – Max 600 PSI
  • Remco Accumulator Tank
  • On/Off Toggle Switch
  • *Deep Cycle Battery & Battery Box
  • NOCO Battery Charger & Battery Tender
  • 55 Gallon Bleach Tank -with custom fabricated, heavy-duty hold-down bands
  • Poly Gun/Wand Assembly with Quick Connecting Stainless Steel JROD with 0°, 15°, 25°, 40° Spray Nozzles
  • Dipstick Assembly : used for drawing chemical into soft wash system, for rinsing your soft wash by dropping dipstick into water tank, and for transferring chemicals.
  • Soft Wash Proportioner:
    • Solid Heavy Duty Manifold
    • Chemical Resistant Bleach Metering Valve
    • Water Metering Valve
    • Surfactant Metering Valve
    • Includes: 7 Gal surfactant tank, hardware, plumbing, and installation
  • All Mounted On 24’x24′ Aluminum Diamond Plate Panel

Install Package:

  • 525 Gallon Water Tank
    • Tank Overflow Valve – 3/4″ water fill – stop water flow when tank is full and will continue to fill when water level drops
    • Tank Drain – 2″ Ball Valve that releases to the bottom passenger side of the van
    • Heavy Duty Water Tank Filter – to help keep debris out of your equipment
    • Garden Hose Fitting for Easy Connection of Inlet Hose
    • Heavy Duty Hold-Down Bands
  • Cool Bypass System for Pressure Washer – protects the pressure washer pump from overheating when trigger is released.
  • Titan Aluminum High Pressure Hose Reel (1)
    • 12v Electric Rewind
    • 1/2″ Stainless Steel Manifold
    • Holds max of 300′ of 3/8″ hose
    • 200′ High Pressure Hose, Gray, 1WB, 4200 PSI
    • Includes Locking Pin
  • Titan Aluminum High Pressure Hose Reel (2)
    • 12v Electric Rewind
    • 1/2″ Stainless Steel Manifold
    • Holds max of 300′ of 3/8″ hose
    • 200′ High Pressure Hose, Gray, 1WB, 4200 PSI
    • Includes Locking Pin
  • Titan Aluminum Inlet Hose Reel
    • 12v Electric Rewind
    • Stainless Steel Manifold
    • Holds max of 100′ of 3/4″ hose
    • 100′ Flexzilla Inlet Hose
    • Includes Locking Pin
  • Titan Aluminum Soft Wash Hose Reel:
    • 12v Electric Rewind\
    • Stainless Steel Manifold
    • Holds max of 200′ x 1/2″ hose
    • Includes 200′ x 1/2″, 600 PSI yellow soft wash hose
    • Includes Locking Pin
  • (2) Titan Stack Brackets
  • 7 Gallon Surfactant Tank
  • Heavy Duty Water Tank Filters – for easy cleanout and maintenance
  • Chemical Resistant Flooring – Grey diamond plate texture: protects against moisture and corrosive SH
  • (2) Stainless Steel 6000 PSI Ball Valve Assemblies
  • Downstream Manifold: pull up to four different soaps or chemicals using your downstream soap injector through the pressure washer.  Each soap/chemical line plumbed with a ball valve to regulate which items you want to draw or have turned off.  Includes pictured 20g soap tank.
  • 22 Gallon Aluminum Fuel Tank
  • 24′ Aluminum Telescopic Wand
  • Aluminum Hose Reel Stand
  • 24″ BE Stainless Steel Surface Cleaner
  • Painted Interior Walls & Doors
  • (3) Batteries & Battery Boxes
  • Wall Hooks
  • 48″ Quick Connect Wand Extension
  • 96″ Quick Connect Wand Extension



Add On Options (all pictured in listing photos and video):

  • EZ Winterize System – quickly and easily winterize your whole system to protect against freezing.  Comes with 20 gallon tank for antifreeze.
  • Downstream Schertz Box – remote rinse for downstream soap injector.
  • 12v Schertz Box – remote rinse for your 12v soft wash system
  • Add premium hose guides to all four 12″ hose reels – reel up or unwind your hose with ease!



*This install fits into a 14′ Ford F-350 Transit High Top Cargo Van.  For installs in vans that do not have the same dimensions as this style, please contact our Build Team at 330-753-8394 for a custom quote!  Pricing does not include the vehicle itself.  Vehicles are to be provided by the customer.

***If you plan to finance a trailer unit or machinery, final transactions for those items must take place with a 3R associate, pending approval of your application.  All website transactions must be paid in full at checkout.  If you have any questions about the financing process or timelines, please call us at 330-753-8394 or at 800-824-8252.  Thank you!
