PYTHON: Customizable 16′ Ford Transit 350HD Van Installation – 8 GPM Cold Pressure Washer, 11 GPM Gas Engine Soft Wash & 7 GPM 12v Soft Wash

PYTHON: Customizable 16′ Ford Transit 350HD Van Installation – 8 GPM Cold Pressure Washer, 11 GPM Gas Engine Soft Wash & 7 GPM 12v Soft Wash

PYTHON: Customizable 16′ Ford Transit 350HD Van Installation – 8 GPM Cold Pressure Washer, 11 GPM Gas Engine Soft Wash & 7 GPM 12v Soft Wash

$29,192.00

Available to Order - call for current lead time

Choose as few or as many of these add-on options to your trailer as you’d like! The pictures on this listing include ALL of the add-on products listed.

**Lead times may vary – standard production of a custom install takes two weeks.  Please call our office for the most accurate production time 330-753-8394.

Description

Cold Water Pressure Washer:

  • 3500 PSI, 8 GPM
  • Honda GX690 Gas Engine with Electric Start
  • Belt Drive General Pump Industrial Series Triplex Pump
  • Powder Coated Skid Frame
  • Battery Cables
  • External Unloader & Thermal Relief Valve
  • Downstream Soap Injection – 20% adjustable draw
  • Bleeder Valve / Pump Primer – bleeds air out of incoming water hose for pressure washer, allowing for easy start-up & preventing pump damage

Gas Soft Wash System:

  • 300 PSI, 11 GPM
  • Honda GX160 Gas Engine
  • Electric Start
  • Engine Oil Drain Hose
  • Corrosion Resistant Aluminum Skid Frame
  • Anti-Vibration Rubber Isolators
  • Featuring the Comet P40 Pump or AR45 Pump
  • Proportioner System for Soft Wash:
    • Pull water, surfactant, and sodium hypochlorite without the need for batch mixing
    • Easily change solution ratios
    • Hi-Flow metering valves: no stress on pump and greater spray distance
    • Second soap valve optional
    • Flush Valve
    • Custom fabricated brackets for mounting
  • 55 Gallon S/H Tank
  • High Flow Rear Entry Red Wash Down Gun

12V Soft Wash System:

  • 100 PSI, 7 GPM Remco Diaphragm Pump
  • 200′ x 1/2″ of Yellow Soft Wash Hose – Max 600 PSI
  • Remco Accumulator Tank
  • On/Off Toggle Switch
  • *Deep Cycle Battery & Battery Box
  • NOCO Battery Charger & Battery Tender
  • 55 Gallon Bleach Tank -with custom fabricated, heavy-duty hold-down bands
  • Poly Gun/Wand Assembly with Quick Connecting Stainless Steel JROD with 0°, 15°, 25°, 40° Spray Nozzles
  • Dipstick Assembly : used for drawing chemical into soft wash system, for rinsing your soft wash by dropping dipstick into water tank, and for transferring chemicals.
  • Soft Wash Proportioner:
    • Solid Heavy Duty Manifold
    • Chemical Resistant Bleach Metering Valve
    • Water Metering Valve
    • Surfactant Metering Valve
    • Includes: 7 Gal surfactant tank, hardware, plumbing, and installation
  • All Mounted On 24’x24′ Aluminum Diamond Plate Panel

Install Package:

  • 325 Gallon Water Tank
    • Tank Overflow Valve – 3/4″ water fill – stop water flow when tank is full and will continue to fill when water level drops
    • Tank Drain – 2″ Ball Valve that releases to the of the passenger side of the van
    • Heavy Duty Water Tank Filter – to help keep debris out of your equipment
    • Garden Hose Fitting for Easy Connection of Inlet Hose
    • Heavy Duty Hold-Down Bands
  • Cool Bypass System for Pressure Washer – protects the pressure washer pump from overheating when trigger is released.
  • Titan Aluminum High Pressure Hose Reel
    • 1/2″ Stainless Steel Manifold
    • Holds max of 400′ of 3/8″ hose
    • 200′ High Pressure Hose, Gray, 1WB, 4200 PSI
    • Includes Locking Pin
    • Quick Connect Fitting Installed On Reel: to secure hose while in-transit
  • Titan Aluminum Inlet Hose Reel
    • Stainless Steel Manifold
    • Holds max of 150′ of 3/4″ hose
    • 100′ Flexzilla Inlet Hose
    • Includes Locking Pin
    • Quick Connect Fitting Installed On Reel: to secure hose while in-transit
  • Titan Aluminum Soft Wash Hose Reel (Gas SW):
    • Stainless Steel Manifold
    • Holds max of 300′ x 1/2″ hose
    • Includes 200′ x 1/2″, 600 PSI yellow soft wash hose
    • Includes Locking Pin
  • Titan Aluminum Soft Wash Hose Reel (For 12v)
    • Stainless Steel Manifold
    • Holds max of 300′ x 1/2″ hose
    • Includes 200′ x 1/2″, 600 PSI yellow soft wash hose
    • Includes Locking Pin
  • (2) Titan Stack Brackets & Additional Custom Fabricated Supports
  • 7 Gallon Soap Tank
  • Heavy Duty Water Tank Filters – for easy cleanout and maintenance
  • Chemical Resistant Flooring – Grey diamond plate texture: protects against moisture and corrosive SH
  • Stainless Steel 6000 PSI Ball Valve Assembly
  • Tool Box Cabinet
  • Downstream Manifold: pull up to four different soaps or chemicals using your downstream soap injector through the pressure washer.  Each soap/chemical line plumbed with a ball valve to regulate which items you want to draw or have turned off.  Includes extra soap tank.
  • *Concession door with hydraulic struts for easy access to hose reels.
  • Installation – installation of above components into pictured van, including labor, additional plumbing, hardware, & fittings
  • Training – Operations, winterization, and safety & maintenance training provided at pick up.  Typically takes 30-90 minutes depending on the complexity of your build



Add On Options (all pictured in listing photos and video):

  • Remote Rinse System for Gas Engine Soft Wash (installation included): From a distance, you can flush out your soft wash system completely, or switch from pulling SH to water with the push of a button!
  • EZ Winterize System – quickly and easily winterize your whole system to protect against freezing.  Comes with 20 gallon tank for antifreeze.
  • Schertz Box – remote rinse for downstream soap injector.
  • Add premium hose guides to all four 18″ hose reels – reel up or unwind your hose with ease!



Check out the video we did for this custom build below



*This install fits into a 16′ Ford Transit 350HD Van.  For installs in vans that do not have the same dimensions as this style, please contact our Build Team at 330-753-8394 for a custom quote!  Pricing does not include the vehicle itself.  Vehicles are to be provided by the customer.

**Concession door size may vary depending on what sizes are available at time of build.

****Lead times may vary. standard production of a custom skid unit takes one-two weeks.  Please call our office for the most accurate production time  330-753-8394.

***If you plan to finance a trailer unit or machinery, final transactions for those items must take place with a 3R associate, pending approval of your application.  All website transactions must be paid in full at checkout.  If you have any questions about the financing process or timelines, please call us at 330-753-8394 or at 800-824-8252.  Thank you!
