ORIOLE: Customizable 48″x40″ Aluminum Pallet Assembly – 3000 PSI, 5.5 GPM Pressure Washer

ORIOLE: Customizable 48″x40″ Aluminum Pallet Assembly – 3000 PSI, 5.5 GPM Pressure Washer

ORIOLE: Customizable 48″x40″ Aluminum Pallet Assembly – 3000 PSI, 5.5 GPM Pressure Washer

$8,474.00

Please chose any of the following upgrade or options for your build. For more detail on some of these options, please check the bottom of the listing.

Finance payments as low as $208/mo!  Click here for more information

Description

The options are endless with these Aluminum Pallet Assemblies!  Great for installation in truck beds, vans, flatbeds, and more, these skid assemblies help minimize the amount of products being secured directly into your vehicle, and make a great use of space.  Another bonus is the entire base is constructed of chemical-resistant aluminum, helping to extend the life of the assembly.  These are an excellent option for those who want a compact set-up for getting into congested areas, someone who doesn’t want to pull a trailer, serving as an secondary or backup system,  or for someone who wants a system that can be easily moved from vehicles down the road.

Included in the Package:

  • 48″x40″ Aluminum Pallet Base
    • 4-way Fork Access for Easy Installation
  • 3000 PSI, 5.5 GPM Cold Water Pressure Washer
    • Belt Drive General Pump Triplex Plunger Pump
    • Honda GX390 Engine – ELECTRIC START
      • Includes battery, battery box, and installation
    • External Unloader
    • Thermal Relief
    • Skid Frame w/Rubber Isolators
    • 36″ Wand Assembly with Quick Connect Fittings
    • Trigger Gun w/ Safety Lock-Off
    • 0°, 15°, 25°, 40° Color Coded Quick Connect Spray Nozzles
  • 100 Gallon Flat Bottom Water Tank with Hold Down Bands – includes inlet plumbing, 1″ tank drain with 4′ hose and valve, and float valve.  This is intended to be installed behind or close by your skid assembly, not on the pallet itself.  Dimensions of this tank are approximately 27″ W x 29″ H x 43″ L.  (This tank is not pictured in the photos)
  • Cool Bypass System for Pressure Washer – protects the pressure washer pump from overheating when trigger is released
  • Downstream Soap Injection for the Pressure Washer – Low pressure soap application with an adjustable soap draw up to a 20% ratio.  When spraying soap with your pressure washer, the soap injector does all the diluting for you.  Injector is activated when using the provided low pressure quick connect soap nozzle provided.
    • 3-Way ball valve on hose reel allows for you to pull bleach from the 55 gallon bleach tank on your skid, or with the twist of the valve handle, pull any other detergent by dropping the attached suction line & strainer into the solution of your choice.
    • 16 Gallon Soap Tank
  • EZ Winterize System – with 7 gallon antifreeze tank : Quickly winterize your pressure washer – including reels, hoses, plumbing, and more!
  • Stainless Steel Hose Reel Stack Bracket
  • Inlet Hose Reel – Titan 3/4″ x 150′ Max – Aluminum Construction, Stainless Steel Manifold,  12″ PVC Barrel – 1/2″ Swivel
    • Comes with 100′ x 3/4″ Flexzilla hose installed on reel
    • Quick Connect Fitting Installed On Reel: to secure hose while in-transit
    • Includes Locking Pin
  • Pressure Washer Hose Reel – Titan 3/8″ x 300′ Max – Aluminum Construction, Stainless Steel Manifold,  12″ PVC Barrel – 1/2″ Swivel
    • Comes with the 200′ x 3/8″ gray hose installed on reel
    • Quick Connect Fitting Installed On Reel: to secure hose while in-transit
    • Includes Locking Pin
  • Approximate Overall Dimensions: 47.5″ W* x 49″ L x 41″ H
  • With hose reel handles attached.  When handles are removed, it’s 43″W)

Add-On Options Available:

*Tanks below are to be installed behind, or close by to the pallet assembly, not on the pallet assembly.  If you are interested in a skid assembly where the water tank is included on the pallet itself, please check out our CONDOR Skid Assembly.

  • Upgrade to 325 Gallon Horizontal Leg Water Tank with Hold Down Bands – includes inlet plumbing, 1″ tank drain with 4′ hose and valve, and float valve (this size cannot be shipped – pick up only)
    • Tank dimensions: 38″ Diameter x
  • Upgrade to 200 Gallon Flat Bottom Water Tank with Hold Down Bands – includes inlet plumbing, 1″ tank drain with 4′ hose and valve, and float valve
    • Tank dimensions:
  • Upgrade to 100 Gallon Loaf Water Tank with Hold Down Bands – includes inlet plumbing, 1″ tank drain with 4′ hose and valve, and float valve (this option has a more narrow footprint, making it more ideal for compact spaces)
    • Tank dimensions: 20″ W x 32″H x 48″L

Benefits of this package:

  • Pressure Washer:
    • Clean siding, driveways, sidewalks, decks, vehicles, and more
    • 5.5 GPM flow will help you get jobs done faster, and increasing your spray height, allow you to do more jobs in one day
    • Belt driven pumps run at a lower RPM than direct drive pumps.  This reduces wear and extends the lifespan of your equipment
      • All triplex plunger pumps come with a 5 year manufacturer warranty
    • Commercial duty Honda engines are widely recognized as reliable, heavy-duty, and come with a a 3 year factory warranty
    • Cool Bypass System also helps extend the life of your pump and saving you from costly repairs
    • Soft wash siding with a low pressure soap nozzle (DO NOT use a pressure washer under any circumstance on a ROOF)
  • Hose Reels:
    • Highly sought after Titan hose reels
    • Full aluminum frames with stainless steel manifolds for the ultimate corrosion resistance
    • Heavy duty swivels installed on each reel
  • Assembly:
    • Compact set-up
    • Easy to move in and out of vehicles
    • Only securing one piece of equipment to your vehicle versus several pieces
    • Aluminum pallet is corrosion resistant – extends the life of your build and adds to the aesthetics
    • Professional Assembly – with over 27 years of experience building mobile wash equipment, we can put together a compact, high-functioning, long-lasting rig that looks great, too!
    • All items for builds are IN STOCK –  no waiting for pieces and parts to come in.
    • All equipment is top-of-the-line commercial-grade equipment.  We don’t cut corners – we build rigs to last.
    • Custom fabricated bands and brackets give builds a high-functioning ability, and sleek look
  • Other Benefits:
    • These pallet assemblies can be shipped!
    • They have high profit potential – less time setting up and tearing down on a job site means more time available to book more jobs!



  1. Installation of the pallet assembly into your vehicle is not included.  Please contact us at 330-753-8394 for pricing on this service.  Service only available at our Barberton, OH location.
  2. Weights and overall dimensions are subject to change.  For questions, please contact the office at 330-753-8394.
  3. Lead times may vary– standard production of a custom skid unit takes one-two weeks.  Please call our office for the most accurate production time 330-753-8394.
  4. If you plan to finance a unit or machinery, final transactions for those items must take place with a 3R associate, pending approval of your application.  All website transactions must be paid in full at checkout.  If you have any questions about the financing process or timelines, please call us at 330-753-8394 or at 800-824-8252.  Thank you!
