MUDSLIDE: Customizable 20′ Flatbed Trailer – 3500 PSI, 5.5 GPM Hot Water Washer, 300 PSI, 11 GPM Gas Soft Wash System

Description

Check out the MUDSLIDE!  The MUDSLIDE was originally built for a customer who plans to add a wastewater recovery system on the back of this trailer.  The 525 gallon tank on board is intended to be used as the recovered water tank, and the 325 gallon tank on board is for fresh water that is being fed from your inlet hose reel.  This trailer can be customized further to add a wastewater recovery system that we install, we can consolidate the 525 and 325 gallon water tanks to be one large tank if you do not need the recovery system, or we can change the size of the trailer to something smaller.  The sky is the limit!  If you’d like to discuss a modification that is not available online, please give us a call at 330-753-8394.

Trailer:

• 20′ x 8′ Flatbed Tandem Axle Trailer
• No Side Rails
• 8,000 lb Axles (each)

Hot Pressure Washer:

• 3500 PSI, 5.5 GPM
• 20hp Honda GX630 Engine, Twin Cylinder – Electric Key Start
• Belt Drive Triplex Plunger Pump – Heavy Duty T Series General Pump
• EZ Align Belt Tensioning System: allows for easy, single bolt, belt tensioning adjustments.
• Stainless Steel Frame, Coil Wrap & Panels: rugged & durable stainless steel offers corrosion resistance and protection of your valuable investment from the harshest environments.  Keeps you machine looking like new for years to come.
• 12v Diesel Burner System
• 546,000 BTU
• Spiralast Coil: manufactured by Hydro Tek – Robotically fused 1/2″ schedule 80 steel pipe is cold rolled to protect the steel pipe from fatigue.  The coil is then surrounded by ceramic insulation and stainless enclosure with double-wall end caps.  Lifetime Coil Warranty.
• 8 Gallon Gas and Diesel Tanks: Heavy duty “roto-molded” rust free fuel tanks with fuel filter to protect against contaminated fuel. Safely refuel tanks away from hot engine. Extended run time with larger fuel capacity.
• Adjustable Thermostat
• Burst Disc Technology for Operator Safety
• 250 Degree Steam Setting
• Cool Bypass System for Pressure Washer – protects the pressure washer pump from overheating when trigger is released.
• Downstream Soap Injection – 20% Adjustable draw

Gas Soft Wash System:

• 300 PSI, 11 GPM
• Honda GX160 Gas Engine
• Electric Start
• Engine Oil Drain Hose
• Corrosion Resistant Aluminum Skid Frame
• Anti-Vibration Rubber Isolators
• Featuring the Comet P40 Pump or AR45 Pump
• Proportioner System for Soft Wash:
  • Pull water, surfactant, and sodium hypochlorite without the need for batch mixing
  • Easily change solution ratios
  • Hi-Flow metering valves: no stress on pump and greater spray distance
  • Second soap valve optional
  • Flush Valve
  • Custom fabricated brackets for mounting
  • 7 Gallon Surfactant Tank
• 50 Gallon S/H Tank
• High Flow Rear Entry Red Wash Down Gun
• Soft Wash Pressure Gauge – installed on reel

Install Package:

• 325 Gallon Water Tank – for fresh water
  • Tank Overflow Valve – 3/4″ water fill – stop water flow when tank is full and will continue to fill when water level drops
  • Tank Drain – 2″ Ball Valve that releases to the side of the trailer
  • Heavy Duty Water Tank Filter – to help keep debris out of your equipment
  • Heavy Duty Hold-Down Bands
• 525 Gallon Water Tank – for captured water (from reclaim system being added by the customer in this particular case.  We can also provide recycle systems.)
• (2) 35 Gallon Soap Tanks
• Three Stacked Titan Electric Rewind Hose Reels:
  • 450′ x 3/8″  Aluminum Titan High Pressure 18″ Hose Reel (Pressure Washer)
    • 200′ High Pressure Hose – Gray
    • 18″ Stainless Steel Premium Hose Guides
    • Stainless Steel Manifold
  • 300′ x 1/2″ Aluminum Titan High Pressure 18″ Hose Reel (Soft Wash)
    • 200′ Soft Wash Hose – Yellow
    • 18″ Stainless Steel Premium Hose Guides
    • Stainless Steel Manifold
  • 150′ x 3/4″ Aluminum Titan Inlet 18″ Hose Reel
    • 100′ Flexzilla 3/4″ Inlet Hose
    • 18″ Stainless Steel Premium Hose Guides
    • 1″ Iron Manifold – for faster filling of the water tank
• Locking Quick Connect & Twist Lock Fittings on Hose Reels
• Stainless Steel Titan Stack Bracket
• Heavy Duty T-Strainer Water Filter: placed before proportioner system to prevent debris from clogging metering valves and pump
• Installation – installation of above components into pictured van, including labor, additional plumbing, hardware, & fittings
• Training– Operations, Maintenance & Safety Training provided at pick up.  Our technicians will provide hands on training so you are completely comfortable with your build before you leave our facility.   Training can be for one person or for your whole team.

Add-On Options (all pictured in photos):

• Chemical Resistant Protective Flooring: upgrade from painted floors to our protective floor covering.  Protects wood floor of trailer from water & harsh chemicals.  Slip Resistant.  Gray Diamond plate pattern.  A 3R exclusive option!
• Remote Rinse System for Gas Engine Soft Wash (installation included): From a distance, you can flush out your soft wash system completely, or switch from pulling SH to water with the push of a button!
• Downstream Manifold: Pull three different soaps or chemicals using your downstream soap injector through the pressure washer.  Each soap/chemical line plumbed with a ball valve to regulate which items you want to draw or have turned off.

**If you plan to finance a trailer unit or machinery, final transactions for those items must take place with a 3R associate, pending approval of your application.  All website transactions must be paid in full at checkout.  If you have any questions about the financing process or timelines, please call us at 330-753-8394 .  Thank you!
